Shanling M2X Portable Music Player
Shanling M2x will come with few new features:
- Tidal support ‰ۡÌÝÌÕ For never-ending streaming of music (ONLINE mode only)
- USB Bluetooth transmitter ‰ۡÌÝÌÕ For high quality wireless sound from any computer
- Advanced USB output ‰ۡÌÝÌÕ For use with any external USB DAC, now including compatibility with DLNA, Airplay and Bluetooth receiver̴Ì_modes
- USB Bluetooth transmitter ‰ۡÌÝÌÕ For high quality wireless sound from any computer
- Advanced USB output ‰ۡÌÝÌÕ For use with any external USB DAC, now including compatibility with DLNA, Airplay and Bluetooth receiver̴Ì_modes
Other features:
- MTouch 2.0 system
- Bluetooth 4.2, two-way connection
- LDAC, AAC, apt-X, SBC support
- 2.5 mm balanced and 3.5 mm single-ended output
- USB DAC function
- DLNA & Airplay support
- OTA upgrades
- 3.2 inch touch screen
- Single micro SD card slot
- Bluetooth 4.2, two-way connection
- LDAC, AAC, apt-X, SBC support
- 2.5 mm balanced and 3.5 mm single-ended output
- USB DAC function
- DLNA & Airplay support
- OTA upgrades
- 3.2 inch touch screen
- Single micro SD card slot
Shanling M2X Specification
Audio Circuit:- single AKM AK4490EN DAC
- single TI OPA1612 acting as the low-pass filter
- dual AD8397 amplifier
Dimensions: 98 x 60 x 16 mm
Weight: 147 g
Battery:
- 2400 mAh, fully charged in 2.5 hour
- 10.5 hours of playback in Single ended mode
- 7.5 hours of playback in Balanced mode
Hi-Res sound support:̴Ì_
- PCM up to 32bit/384kHz, DSD up to DSD256
Audio output Single ended (3.5 mm jack):
- Output power 180 mW @ 16 Ohm / 106 mW @ 32 Ohm
- SNR 117 dB (A-weighting)
- Output impedance 1 Ohm
- Channel separation 70 dB (32 Ohm)
Audio output Balanced (2.5 mm jack):
- Output power 212 mW @ 16 Ohm / 120 mW @ 32 Ohm
- SNR 116 dB (A-weighting)
- Output impedance 2 Ohm
- Channel separation 107 dB (32 Ohm)
